Why Choose the HICLOVER TS50 PLC?

1. High Throughput & Efficiency

• Burn rate: approximately 50 kg/hr, enabling reliable waste processing even during peak usage. (clover-incinerator.com)

• Feed capacity: up to 100 kg per charge, ensuring fewer loading cycles and enhanced operational efficiency. (clover-incinerator.com)

2. Advanced Combustion Performance

• Dual-chamber design:

  • Primary chamber: 560 L

  • Secondary chamber: 280 L (clover-incinerator.com)

• Temperature zones:

  • Primary: 800–1000 °C

  • Secondary: 1000–1200 °C (clover-incinerator.com)

• Residence time: 2.0 seconds—designed to exceed standards for complete incineration and gas cleanup. (clover-incinerator.com)

3. Smart Controls & Safety

• PLC automatic control means fully programmable, monitored incineration suited to institutional needs.

• Intelligent sensors support continuous feeding while protecting workers from exposure.

• Adjustable High‑Temperature Retention (HTR) helps optimize emissions control and fuel usage.

• Intelligent fuel-saving mode adjusts consumption automatically.

4. Robust Build & Specifications

• Internal dimensions: 100 × 80 × 70 cm. (clover-incinerator.com, clover-incinerator.com)

• Feed door size: 70 × 55 cm—large enough to handle bulk waste with ease. (clover-incinerator.com)

• Fuel usage:

  • Diesel: 12.1–24 kg/hr

  • Typical average: ~16.9 kg/hr

  • Gas: ~20 m³/hr (clover-incinerator.com)

• Electrical power: 0.7 kW, standard 220 V input.

• Oil tank: 100 L reservoir. (clover-incinerator.com)

• Chimney: 5 m stainless steel chimney ensures compliance and efficient exhaust. (clover-incinerator.com)

Environmental & Compliance Benefits

• Smoke filter chamber included to effectively capture particulates. (clover-incinerator.com)

• Capable of gasified‑pyrolysis incineration, ensuring low emissions of dust and dioxins—ideal for infectious waste. (clover-medical.com)

• Features fully enclosed operation, minimizing risk of worker exposure and secondary contamination.

Why It Matters for a 240-Bed Hospital

1. Capacity-aligned waste processing
   – With ~240 beds, daily medical waste can reach several hundred kilograms; a 50 kg/hr burn rate ensures uninterrupted throughput.

2. Safety first
   – PLC and intelligent sensor controls automatically detect and respond to feed/temperature changes, reducing operator risk.

3. Compliance-ready setup
   – Dual-chamber system, smoke filtration, and controlled emissions meet international waste management standards.

4. Cost-effective operation
   – Intelligent fuel-saving and optimized retention cut energy costs and reduce long-term operating expenses.

5. Scalable & future-ready
   – The modular nature of the TS series allows future upgrades (e.g., TS100 PLC) if hospital expansion is anticipated.

Summary Table

Final Thoughts

The HICLOVER TS50 PLC is a robust, smart, and environmentally conscious incinerator—tailored perfectly to support the operational demands and regulatory requirements of Algeria’s new 240-bed hospital. Its balance of capacity, automation, safety, and compliance makes it a strategic asset for healthcare waste management. A cutting-edge 240-bed medical facility in Algeria has recently opened its doors, the HICLOVER TS50 PLC medical waste incinerator. Designed with both environmental sustainability and staff safety in mind, this advanced system enhances waste management efficiency and regulatory compliance—crucial for modern healthcare operations.
