Incinerator Items/Model |
HICLOVER TS30(PLC)
|
HICLOVER TS50(PLC)
|
HICLOVER TS100(PLC)
|
|
|
Burn Rate (Average) |
30-50 kg/hour |
50-100 kg/hour |
100-150 kg/hour |
|
|
Feed Capacity(Average) |
60kg/feeding |
100kg/feeding |
350kg/feeding |
|
|
Control Mode |
PLC Automatic |
PLC Automatic |
PLC Automatic |
|
|
Primary Combustion Chamber |
330L(0.33M3) |
560L(0.56M3) |
1810L(1.81M3) |
|
|
Internal Dimensions |
75x75x60cm |
100x80x70cm |
165x110x100cm |
|
|
Secondary Chamber |
180L |
280L |
660L |
|
|
Smoke Filter Chamber |
Yes |
Yes |
Yes |
|
|
Feed Mode |
Manual |
Manual |
Manual |
|
|
Voltage |
380V±10%, 50Hz |
380V±10%, 50Hz |
380V±10%, 50Hz |
|
|
Power |
5.0Kw |
6.0Kw |
8.0Kw |
|
|
Burner Type |
Italy Brand |
Italy Brand |
Italy Brand |
|
|
Oil Consumption (kg/hour) |
12 |
12 |
16 |
|
|
N.Gas Consumption (m3n/hour) |
16 |
21 |
25 |
|
|
Temperature Monitor |
Yes |
Yes |
Yes |
|
|
Temperature Thermometer |
Corundum Probe Tube, 1400℃Rate. |
Corundum Probe Tube, 1400℃Rate. |
Corundum Probe Tube, 1400℃Rate. |
|
|
Temperature Protection |
Yes |
Yes |
Yes |
|
|
Automatic Cooling |
Yes |
Yes |
Yes |
|
|
Automatic False Alarm |
Yes |
Yes |
Yes |
|
|
Automatic Protection Operator(APO) |
Yes |
Yes |
Yes |
|
|
System Testing Model |
Yes |
Yes |
Yes |
|
|
Time Setting |
Yes |
Yes |
Yes |
|
|
Progress Display Bar |
LCD Display |
LCD Display |
LCD Display |
|
|
Oil Tank |
200L |
200L |
200L |
|
|
Oil Tank Stand |
190cm Height |
190cm Height |
190cm Height |
|
|
Liquid level Display |
Yes |
Yes |
Yes |
|
|
Feeding Door |
40x40cm |
50x50cm |
60x70cm |
|
|
Chimney |
10Meter |
10Meter |
10Meter |
|
|
Chimney Type |
Stainless Steel 304 |
Stainless Steel 304 |
Stainless Steel 304 |
|
|
1st. Chamber Temperature |
800℃ Related posts:  | |||
